[Upgraded] BlueStars DG94-01012A Gas Oven Igniter - Compatible with Samsung Oven Range Stove (NX58H95 NX58H99 NX58H NX58J NX58K NX58M NX58N series)- Replaces 4011538 AP5967723 PS5967723 EAP11720750

PRODUCT SPECIFICATIONS Package includes: 1 x DG94-01012A Igniter with silicon carbide tip and wire connector plug; 2 x ceramic nuts Length “A”: 3.7 inches Lead Length: 10 inches (long) and 9 inches (short) Plug Length: 1 inch Electrical rating: 3.0 to 3.6 Amps at 120V AC Heat up Time: 1796°F ≤ 17s Maximum Temperature: 3100°F FIX OVEN’S SYMPTOMS: The oven is not heating up | The oven won’t ignite | Igniter burned out | Unpleasant gas smell | Oven glows but doesn’t spark | Slow or uneven heating REPLACES PART NUMBERS: 316489402, 5304509706, WB2X10016, 316489408, AP6230715, PS12071409, Norton-501a, 316119301, WB02X10016, 1704 41-209, AP2009619, PS241804, 4545981, EAP12071409, etc. COMPATIBLE MODELS: The DG94-01012A Gas Oven Igniter fits for Samsung NX58H, NX58J, NX58K, NX58M, NX58N, and NX58R series gas oven models. NX58H9500WS/AA-00, NX58H9500WS/AA-01, NX58H9500WS/AA-02, NX58H9500WS/AA-03, NX58H9950WS/AA-00, NX58H9950WS/AA-01, NX58J7750SG/AA, NX58J7750SG/AA-00, NX58J7750SS/AA-00, NX58J7750SS/AA-01, NX58K3310SB/AA, NX58K3310SB/AA-00, NX58K3310SS/AA, NX58K3310SS/AA-00, NX58K3310SW/AA, NX58K3310SW/AA-00, NX58K7850SG/AA-00, NX58K7850SG/AA-01, NX58K7850SG/AA-02, NX58K7850SS/AA-00, NX58K7850SS/AA-01, NX58K7850SS/AA-02, NX58K9500WG/AA-00, NX58K9500WG/AA-01, NX58K9500WG/AA-02, NX58K9850SG/AA-00, NX58K9850SG/AA-01, NX58K9850SG/AA-02, NX58K9850SG/AA-03, NX58K9850SS/AA-00, NX58K9850SS/AA-01, NX58K9850SS/AA-02, NX58K9850SS/AA-03, NX58K9850SS/AA-04, NX58K9852SG/AA-00, NX58M6630SG/AA-00, NX58M6630SG/AA-01, NX58M6630SS/AA, NX58M6630SS/AA-00, NX58M6630SS/AA-01, NX58M6650WG/AA-00, NX58M6650WG/AA-01, NX58M6650WG/AA-02, NX58M6650WS/AA-00, NX58M6850SG/AA-00, NX58M6850SG/AA-01, NX58M6850SG/AA-02, NX58M6850SS/AA-00, NX58M6850SS/AA-01, NX58M9420SS/AA-00, NX58M9420SS/AA-01, NX58M9960PM/AA, NX58M9960PS/AA, NX58N9420SG/AA-00, NX58R6631SG/AA-00, NX58R6631SS/AA-00, NX58R6631ST/AA-00, NX58R9421SG/AA-00, etc

• IMPORTANCE NOTES: Length “A”: 3.7 inches | Lead Length: 10 inches (long) and 9 inches (short) | Plug Length: 1 inch | Electrical rating: 3.0 to 3.6 Amps at 120V AC. Each igniter includes a wire connector plug and two ceramic nuts. Because the flame sensor’s ceramic section is fragile, we’ve added foam padding to prevent any cracks or damage during shipping. It has passed anti-aging tests, so don’t worry about any discoloration - it won’t affect performance
• WIDE COMPATIBILITY: The DG94-01012A Igniter replaces part numbers #4011538, AP5967723, PS5967723, EAP11720750, DS039KX. Compatible with Samsung NX58H, NX58J, NX58K, NX58M, NX58N, and NX58R series gas ovens NX58K9500WG/AA-00, NX58M6630SS/AA-00, NX58H9500WS/AA-00, NX58H9500WS/AA-01, NX58H9500WS/AA-02, NX58K7850SS/AA-00, NX58K9850SS/AA-00, NX58H9950WS/AA-00, NX58H9950WS/AA-01, etc. Please check the detailed list below. You can send us your oven model, and we can help you confirm if it fits or not
• SUPERIOR MATERIALS: Crafted with a high-quality silicon carbide tip, crack-resistant ceramic insulation, and reinforced aluminum alloy bracket, the DG94-01012A oven igniter offers superior heat resistance and exceptional longevity. It rapidly reaches ignition temperatures of 1796°F within 17 seconds and reliably withstands extreme oven conditions up to 3100°F for stable cooking performance
• EASY INSTALLATION: For safe installation, always disconnect the oven from power and gas before beginning, for a secure repair experience. 1 - Take out the oven racks, bottom panel, and flame spreader. 2 - Unscrew the burner shield, unplug the igniter connector, and remove mounting screws. 3 - Attach the new igniter to the burner, reconnect the 2-pin connector, and secure it in place. 4 - Reinstall the shield, panel, and racks. Restore power and test oven ignition
• 100% LIFETIME PROTECTION: Enjoy reliable performance with our lifetime protection, ensuring your product is always covered for any defects or issues that may arise
