Digital Pressure Gauge (Range: 0 to 700 Bar / 0 to 10152 Psi) Certified Calibrated | Hydraulic Pressure Gauge | Industrial Pressure Gauge | tire Pressure Gauge | Model: DPG
4.6 (66 items)
Limited Time Sale$81.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210907050 | Release Date | 2026/04/04 | List Price | $54.00 | Model Number | 210907050 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
DPG Series Digital Pressure Gauge. Applications: Ideal for commercial and industrial applications in both test measurement and general purpose installations. Case Size: 2.5". Case material: ABS Plastic. Rubber Boot Included (Silicone Rubber). LCD Display: 2" x 3/4". Connection: 1/4" NPT (304 SS) Bottom. Sensor: 316L SS Welded, Piezo. Operating Life: 1 million cycles. Power Supply: 2 x AAA batteries. Power Mode: Auto or manual shut-off. Display Digits: 4 digits to 5,000 psi, 5 digits to 15,000 psi. Pressure Units: psi, mH2O, mmHg, mbar, kPa for gauge ranges less than or equal to 100 psi. psi, bar, kg/cm2, MPa, atm for gauge ranges greater than or equal to 160 psi. Response Time: Less than or equal to 3 Hz display refresh rate. Proof/Burst Pressure: 200%/300% FS. Operating Temp: 14-122 F. Storage Temp: -4-167 F. Accuracy: +/-1%. Enclosure Rating: IP60. Range: 0-10,000 psi.
- Simple 2 button operation | Reset to zero feature | Option for display to remain continuously ON | Backlight available | Peak pressure indication option | 316L welded diaphragm seal | Standard Rubber boot | ASME B40.100 compliant | Selectable Pressure unit
- Range :0-10000 psi, Operating temperature: 14°F to 122°F (-10°C to 50°C) | Storage Temperature: -4°F to 167°F (-20°C to 75°C) | Accuracy: ±0.5% of readings
- Connection: 1/4” NPT 304SS | Case Size: 2.5” (63mm) | Case Material: ABS (IP64) | Rubber Boot: Silicone rubber (IP65) overall cover | Sensor: 316L welded, Piezo | Operating Life: 1 million cycles
- Power Supply: 2 x AAA battery (1.5V) | LCD Display: 2” x 3/4” (48mm x 16mm) with engg. unit Display | Power Mode: Auto or manual shut-off | Resolution: 1 digit | Response Time: ≤ 3 Hz display refresh rate
- Supply Scope: 1 unit of Winters DPG, Instruction manual & Calibration Certificate | Applications: For Commercial and Industrial Applications.
| Brand Name | INSTRUKART |
|---|---|
| Item Weight | 380 Grams |
| Manufacturer | Ace Instruments |
| Material Type | Aluminum |
| Item Dimensions | 4.72 x 3.94 x 2.75 inches |
| Included Components | 1 unit of DPG with an instruction manual and factory calibration certificate |
| Warranty Description | NO Warranty |
